BNC Model 765 Fast Rise Time Pulse Generator

Rated 0 out of 5

Manufacturer Berkeley Nucleonics Corporation (BNC)

Description

The Model 765 Fast Rise Time Pulse Generator offers premium signal integrity with one of the easiest to use touch screen display interfaces in the industry. It only takes a few touches to generate pulses with this unit. The output Voltage can be adjusted up to 5 Volts peak-peak in a window of ±5 Volts with 70 ps edge rate and transitions with minimal overshoot and ringing. The Model 765’s innovative hardware architecture provides the possibility to generate advanced pulse sequences, such as double pulse or quad pulse, with fully independent timing parameters.

Features

Up to 4 channels
< 70 ps rise/fall time (20%-80%)
Adjustable output level from 10 mVpp to 5 Vpp
Adjustable baseline offset ± 2.5 V
Maximum repetition rate 500 MHz per channel
Pulse width from 300 ps to > 1 s
Width resolution 10 ps
Continuous, single, burst, gated, external trigger modes
Trigger in to output jitter < 35ps RMS
19″ rack-mount kit available (3U space required)

Applications

Big physics applications
Experiments colliders
Lasers modulation
Detectors
Strips silicon emulation
Mass spectroscopy
TDT and TDR applications
Radar and sonar systems
Semiconductors tests

Touch Interface

The Model 765 user interface is designed for touch and it has been developed to put all the capabilities of the modern Pulse and Waveform Generators right at your fingertips.

All instrument controls and parameters are accessed through an intuitive UI that recalls the simplicity of Tablets and modern smart phones: touch features and gestures are available to engineers and scientists to create single or multiple pulses (dual, triple and quadruple pulse mode) in few touches.
